| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DM54LS20W/883
NAND GATE, LS SERIES TTL
|
54LS | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
74H30DC
NAND GATE, 8-INPUT, TTL
|
74H | Bulk | Active | NAND Gate | 8 | - | 4.75V ~ 5.25V | - | - | - |
|
|
54LS26DM
NAND GATE, TTL
|
54LS | Bulk | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 1mA, - | - | - |
|
|
5430FMQB
NAND GATE
|
- | Bulk | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 400µA, 16mA | 0.8V | 2V |
|
74F10DC
NAND GATE
|
74F | Bulk | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
MM74HC00J
IC GATE NAND 4CH 2-INP 14DIP
|
74HC | Bulk | Active | NAND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
5420DM
NAND GATE, TTL
|
- | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 16mA | 0.8V | 2V |
|
|
74F11DC
AND GATE, F/FAST SERIES
|
74F | Bulk | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
962DC
IC GATE NAND 14CDIP
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
74F11SCX-NS
AND GATE, F/FAST SERIES, 3 FUNC,
|
74F | Bulk | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
54F02FMQB
QUAD 2-INPUT NOR GATE
|
54F | Bulk | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
DM74S04MX
INVERTER, S SERIES, 6-FUNC, TTL
|
74S | Bulk | Active | Inverter | 1 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
