| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DM54LS30J/883
NAND GATE, LS SERIES TTL
|
54LS | Bulk | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
JM54AC04BCA-RH
54AC04 - HEX INVERTER - (SMD - J
|
- | Bulk | Active | Inverter | 1 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
74F10LC
NAND GATE, F/FAST SERIES, 3-FUNC
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
JM38510/08003BAA
AND GATE, QUAD 2-INPUT
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
54LS26DMQB
NAND GATE, LS SERIES TTL
|
54LS | Bulk | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 1mA, - | - | - |
|
|
JM38510/30001SCA
SPACE 4-CH, 2-INPUT, 4.5-V TO 5.
|
54LS | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
5409FMQB
IC GATE AND 4CH 2-INP 14CFP
|
5409 | Bulk | Active | AND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 250µA, 16mA | 0.8V | 2V |
|
|
54LS11J/883
AND GATE, LS SERIES, 3-FUNC, 3-I
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
54LS09FMQB
AND GATE, LS SERIES
|
54LS | Bulk | Active | AND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 4mA | 0.7V | 2V |
|
|
74F08PC
IC GATE AND 4CH 2-INP 14DIP
|
74F | Bulk | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
5427DM
IC GATE NOR 3CH 3-INP 14CERDIP
|
- | Bulk | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | - | - | - |
|
|
7437PC
IC GATE NAND 4CH 2-INP 14DIP
|
- | Bulk | Active | NAND Gate | 2 | - | 4.75V ~ 5.25V | 1.2mA, 24mA | - | - |
