| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
HCF40106BEY
IC INVERT SCHMITT 6CH 1-IN 14DIP
|
4000B | Tube | Obsolete | Inverter | 1 | Schmitt Trigger | 3V ~ 20V | 6.8mA, 6.8mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
HCF4073M013TR
IC GATE AND 3CH 3-INP 14SO
|
4000 | Tape & Reel (TR) | Obsolete | AND Gate | 3 | - | 3V ~ 20V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
M74HC03B1R
IC GATE NAND OD 4CH 2-INP 14DIP
|
74HC | Tube | Obsolete | NAND Gate | 2 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
HCF4093BEY
IC GATE NAND 4CH 2IN 14DIP
|
4000B | Tube | Obsolete | NAND Gate | 2 | Schmitt Trigger | 3V ~ 20V | 6.8mA, 6.8mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
|
M74HC86B1R
IC GATE XOR 4CH 2-INP 14DIP
|
74HC | Tube | Obsolete | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
74V1T32STR
IC GATE OR 1CH 2-INP SOT23-5
|
74V | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
HCF4070M013TR
IC GATE XOR 4CH 2-INP 14SO
|
4000 | Tape & Reel (TR) | Obsolete | XOR (Exclusive OR) | 2 | - | 3V ~ 20V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
M74HC14YRM13TR
IC INVERT SCHMITT 6CH 1-INP 14SO
|
Automotive, AEC-Q100, 74HC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.5V | 1.5V ~ 4.2V |
|
|
HCF4093YM013TR
IC GATE NAND SCHMIT 4CH 2IN 14SO
|
Automotive, AEC-Q100, 4000 | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 3V ~ 20V | 6.8mA, 6.8mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
|
74AC32MTR
IC GATE OR 4CH 2-INP 14SO
|
74AC | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
74LVC14ATTR
IC INVERTER 6CH 1-INP 14TSSOP
|
74LVC | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.3V ~ 0.8V | 1.4V ~ 2.2V |
|
|
M74HC20RM13TR
IC GATE NAND 2CH 4-INP 14SO
|
74HC | Tape & Reel (TR) | Obsolete | NAND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
