| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
54H20DM
IC GATE NAND 2CH 4-INP 14CERDIP
|
54H | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | - | - | - |
|
9009PC
IC GATE NAND
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
4030BDC
IC GATE XOR
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
4071BDM
IC GATE OR
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
74S32PC
OR GATE, S SERIES, TTL, PDIP14
|
74S | Bulk | Active | NOR Gate | 2 | - | 4.75V ~ 5.25V | - | - | - |
|
|
54ACTQ32JRQMLV
IC GATE OR 4CH 2-INP 14CERDIP
|
54ACTQ | Bulk | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2.2V |
|
DM74S09N
IC GATE AND OP COL 4CH 2IN 14DIP
|
74S | Tube | Obsolete | AND Gate | 2 | Open Collector | 4.75V ~ 5.25V | -, 20mA | 0.8V | 2V |
|
DM54LS32J/883
OR GATE, LS SERIES TTL
|
54LS | Bulk | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
DM54LS20J/883
NAND GATE, LS SERIES TTL
|
54LS | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
MM74HC27M
NOR GATE, HC/UH SERIES
|
74HC | Bulk | Active | NOR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
JM54AC86S2A-RH
54AC86 - QUAD 2-INPUT EXCLUSIVE-
|
54AC | Bulk | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
5401FM
IC GATE NAND
|
- | Bulk | Active | - | - | - | - | - | - | - |
