| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Circuits | Number of Inputs | Schmitt Trigger Input | Output Type | Current - Output High, Low | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SY100EL04ZG
IC GATE AND/NAND 2-INPUT 8-SOIC
|
100EL | Tube | Obsolete | AND/NAND Gate | 1 | 2 | No | Differential | - | 4.2V ~ 5.5V |
|
|
SY10EP08VZI
IC GATE XOR/XNOR 3.3V/5V 8-SOIC
|
10EP | Bulk | Discontinued at | XOR/XNOR Gate | 1 | 2 Input (1, 1) | No | Differential | - | 3V ~ 5.5V |
|
|
SY100EL07ZC
IC GATE XOR/XNOR 2-INPUT 8-SOIC
|
100EL | Bulk | Discontinued at | XOR/XNOR Gate | 1 | 2 | No | Differential | - | 4.2V ~ 5.5V |
|
SY10E104JI
IC GATE AND/NAND QUINT 28-PLCC
|
10E | Bulk | Discontinued at | AND/NAND Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | 4.2V ~ 5.5V |
|
|
SY100E104JY-TR
IC GATE AND/NAND QUINT2IN 28PLCC
|
100E | Tape & Reel (TR) | Obsolete | AND/NAND Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | 4.2V ~ 5.5V |
|
|
SY10EP08VZG
IC GATE XOR/XNOR 2INP DIFF 8SOIC
|
10EP | Tube | Obsolete | XOR/XNOR Gate | 1 | 2 Input (1, 1) | No | Differential | - | 3V ~ 5.5V |
|
SY55851AUKI-TR
IC GATE 3.0GHZ 50OHM 10-MSOP
|
SY55 | Tape & Reel (TR) | Discontinued at | Configurable Multiple Function | 1 | 2 | No | Differential | - | 2.3V ~ 3.6V |
|
|
SY10E101JI-TR
IC GATE OR/NO QUAD 4INPUT 28PLCC
|
10E | Tape & Reel (TR) | Discontinued at | NOR/OR Gate | 4 | 16 Input (4, 4, 4, 4) | No | Differential | - | 4.2V ~ 5.5V |
|
SY10EP05VKG
IC GATE AND/NAND 2INP DIFF 8MSOP
|
10EP | Tube | Obsolete | AND/NAND Gate | 1 | 2 Input (1, 1) | No | Differential | - | 3V ~ 5.5V |
|
|
SY10EL05ZI-TR
IC GATE AND/NAND DIFF 2INP 8SOIC
|
10EL | Tape & Reel (TR) | Discontinued at | AND/NAND Gate | 1 | 2 Input (1, 1) | No | Differential | - | 4.75V ~ 5.5V |
|
|
SY100S318JZ
IC GATE OA/OAI 5-WIDE 28-PLCC
|
100S | Tube | Obsolete | AND/OR Gate | 1 | 19 Input (5, 4, 4, 4, 2) | No | Differential | - | 4.2V ~ 5.5V |
|
|
SY55851AUKG-TR
IC GATE UNIV 3GHZ 50 OHM 10-MSOP
|
SY55 | Tape & Reel (TR) | Active | Configurable Multiple Function | 1 | 2 | No | Differential | - | 2.3V ~ 3.6V |
