| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Circuits | Number of Inputs | Schmitt Trigger Input | Output Type | Current - Output High, Low | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SY100S307JY
IC GATE OR/NOR 28PLCC
|
100S | Tube | Obsolete | NOR/OR Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | -4.2V ~ -5.5V |
|
SY100S302JC-TR
IC GATE OR/NOR QUINT 2IN 28-PLCC
|
100S | Tape & Reel (TR) | Discontinued at | NOR/OR Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | 4.2V ~ 5.5V |
|
SY10EP05VKC
IC GATE AND/NAND 3.3V/5V 8-MSOP
|
10EP | Bulk | Discontinued at | AND/NAND Gate | 1 | 2 Input (1, 1) | No | Differential | - | 3V ~ 5.5V |
|
|
SY100S317JC
IC GATE OA/OAI TRIPLE 28-PLCC
|
100S | Bulk | Discontinued at | AND/OR Gate | 3 | 12 Input (4, 4, 4) | No | Differential | - | 4.2V ~ 5.5V |
|
SY55851AUKG
IC GATE UNIV 3GHZ 50 OHM 10MSOP
|
SY55 | Tube | Active | Configurable Multiple Function | 1 | 2 | No | Differential | - | 2.3V ~ 3.6V |
|
|
SY100E104JI-TR
IC GATE AND/NAND QUINT 28-PLCC
|
100E | Tape & Reel (TR) | Discontinued at | AND/NAND Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | 4.2V ~ 5.5V |
|
|
SY100E101JC
IC GATE OR/NO QUAD 4INPUT 28PLCC
|
100E | Bulk | Discontinued at | NOR/OR Gate | 4 | 16 Input (4, 4, 4, 4) | No | Differential | - | 4.2V ~ 5.5V |
|
SY10EL01ZI
IC GATE OR/NOR 4-INPUT 8-SOIC
|
10EL | Bulk | Discontinued at | NOR/OR Gate | 1 | 4 | No | Differential | - | 4.75V ~ 5.5V |
|
|
SY10EP05VKI
IC GATE AND/NAND 3.3V/5V 8-MSOP
|
10EP | Bulk | Discontinued at | AND/NAND Gate | 1 | 2 Input (1, 1) | No | Differential | - | 3V ~ 5.5V |
|
|
SY100EL05ZC
IC GATE AND/NAND DIFF 2INP 8SOIC
|
100EL | Bulk | Discontinued at | AND/NAND Gate | 1 | 2 Input (1, 1) | No | Differential | - | 4.2V ~ 5.5V |
|
|
SY100S318JC
IC GATE OA/OAI 5-WIDE 28-PLCC
|
100S | Bulk | Discontinued at | AND/OR Gate | 1 | 19 Input (5, 4, 4, 4, 2) | No | Differential | - | 4.2V ~ 5.5V |
|
|
SY10EP01VZC-TR
IC GATE OR/NOR 3.3V/5V 4IN 8SOIC
|
10EP | Tape & Reel (TR) | Discontinued at | NOR/OR Gate | 1 | 4 | No | Differential | - | 3V ~ 5.5V |
