| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Circuits | Number of Inputs | Schmitt Trigger Input | Output Type | Current - Output High, Low | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN72270N
HEX INVERTER
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LVC1G97DCKRE4
IC MULTI-FUNC GATE CONFIG SC70-6
|
74LVC | Tape & Reel (TR) | Discontinued at | Configurable Multiple Function | 1 | 3 | No | Single-Ended | 32mA, 32mA | 1.65V ~ 5.5V |
|
CD4019BMT
IC QUAD AND/OR SELCT GATE 16SOIC
|
4000B | Tape & Reel (TR) | Active | AND/OR Gate | 4 | 2 | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
CD4086BPW
IC EXPND AND-ORINV GATE 14TSSOP
|
4000B | Tube | Obsolete | AND/OR/INVERT Gate | 1 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
SN54LS54J
4-WIDE AND-OR-INVERT GATES 14-CD
|
54LS | Tube | Active | AND/OR/INVERT Gate | 1 | 10 Input (2, 3, 3, 2) | No | Single-Ended | 4mA, 400µA | 4.5V ~ 5.5V |
|
SN74LVC1G98DCKR
IC CONFIG MULT-FUNC GATE SC70-6
|
74LVC | Tape & Reel (TR) | Active | Configurable Multiple Function | 1 | 3 | No | Single-Ended | 32mA, 32mA | 1.65V ~ 5.5V |
|
CD4068BPW
IC 8INPUT NAND/AND GATE 14TSSOP
|
4000B | Tube | Active | NAND/AND Gate | 1 | 8 | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
SN32242N
HEX INVERTER O.D.
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
CD4078BF
CMOS 8-INPUT NOR/OR GATE 14-CDIP
|
- | Tube | Active | NOR/OR Gate | 1 | 8 | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
CD4572UBM
IC CMOS HEX GATE 4INV 16-SOIC
|
4000B | Tube | Active | NOR/NAND/INVERT Gate | 6 | 8 Input (1, 1, 2, 2, 1, 1) | No | Differential | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
SN74LVC1G57DCKR
IC MULT-FUNCTION GATE SC70-6
|
74LVC | Tape & Reel (TR) | Active | Configurable Multiple Function | 1 | 3 | No | Single-Ended | 32mA, 32mA | 1.65V ~ 5.5V |
|
|
100104FC
AND/NAND GATE, 100K SERIES
|
- | Bulk | Active | AND/NAND Gate | 5 | 10 Input (2, 2, 2, 2, 2) | No | Differential | - | -4.2V ~ -5.7V |
