| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Circuits | Number of Inputs | Schmitt Trigger Input | Output Type | Current - Output High, Low | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD4086BPWR
IC EXPND AND-ORINV GATE 14TSSOP
|
4000B | Tape & Reel (TR) | Obsolete | AND/OR/INVERT Gate | 1 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
CD4048BF3A
CMOS MULTIFUNCTION EXPANDABLE 8-
|
4000B | Tube | Active | Multifunction | 1 | 8 | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
SN74LVC1G97YZPRB
PROTOTYPE
|
74LVC | Bulk | Obsolete | Configurable Multiple Function | 1 | 3 | Yes | Single-Ended | 32mA, 32mA | 1.65V ~ 5.5V |
|
SN74LS51DR
IC GATE AND-OR INV 3-INP 14SOIC
|
74LS | Tape & Reel (TR) | Active | AND/OR/INVERT Gate | 2 | 10 Input (3, 3, 2, 2) | No | Single-Ended | 400µA, 8mA | 4.75V ~ 5.25V |
|
|
CD4078BF3A
CMOS 8-INPUT NOR/OR GATE 14-CDIP
|
- | Tube | Active | NOR/OR Gate | 1 | 8 | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
CD4019BPW
IC QUAD AND/OR SLCT GATE 16TSSOP
|
4000B | Tube | Discontinued at | AND/OR Gate | 4 | 2 | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
SN74LVC1G3208YZPR
IC 3-IN POS OR-AND GATE 6-DSBGA
|
74LVC | Tape & Reel (TR) | Active | AND/OR Gate | 1 | 3 Input (2, 1) | No | Single-Ended | 32mA, 32mA | 1.65V ~ 5.5V |
|
CD4086BPWRE4
IC EXPND AND-ORINV GATE 14TSSOP
|
4000B | Tape & Reel (TR) | Obsolete | AND/OR/INVERT Gate | 1 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
CD4086BF3A
CMOS EXPANDABLE 4-WIDE 2-INPUT A
|
4000B | Tube | Active | AND/OR/INVERT Gate | 1 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
CD4068BPWR
IC 8INPUT NAND/AND GATE 14TSSOP
|
4000B | Tape & Reel (TR) | Active | NAND/AND Gate | 1 | 8 | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
M38510/05352BEA
CMOS QUAD AND/OR SELECT GATE 16-
|
4000B | Tube | Active | AND/OR Gate | 4 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
SN74LVC1G98DCKT
IC MULTI-FUNC GATE CONFIG SC70-6
|
74LVC | Tape & Reel (TR) | Active | Configurable Multiple Function | 1 | 3 | No | Single-Ended | 32mA, 32mA | 1.65V ~ 5.5V |
