| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
IR2109S
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tube | Obsolete | Half-Bridge | Synchronous | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.9V | 200mA, 350mA |
|
IRS2109C
IC GATE DRVR MOSFET
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
IR2132STRPBF
IC GATE DRVR HALF-BRIDGE 28SOIC
|
- | Tape & Reel (TR) | Active | Half-Bridge | 3-Phase | 6 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.2V | 250mA, 500mA |
|
IRS2330DJPBF
IC GATE DRVR HALF-BRIDGE 44PLCC
|
- | Tube | Obsolete | Half-Bridge | 3-Phase | 6 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.2V | 250mA, 500mA |
|
IRS26072DSPBF
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tube | Obsolete | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.5V | 200mA, 350mA |
|
|
TLE918021QKXUMA1
IC MOTOR DRIVER 64LQFP
|
- | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - |
|
IR4426
IC GATE DRVR LOW-SIDE 8DIP
|
- | Tube | Obsolete | Low-Side | Independent | 2 | IGBT, N-Channel MOSFET | 6V ~ 20V | 0.8V, 2.7V | 2.3A, 3.3A |
|
IR2183S
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tube | Obsolete | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.7V | 1.9A, 2.3A |
|
IRS44262SPBF
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tube | Obsolete | Low-Side | Independent | 2 | IGBT, N-Channel MOSFET | 11.2V ~ 20V | 0.8V, 2.5V | 2.3A, 3.3A |
|
|
1ED3141MC12HXUMA1
ISOLATED DRIVER
|
- | Tape & Reel (TR) | Active | - | - | - | - | - | - | - |
|
IRS2817DSTRPBF
IC HVIC 8SOIC N
|
- | Tape & Reel (TR) | Active | High-Side and Low-Side | Independent | 2 | N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.2 V | 200mA, 350mA |
|
IRS21834STRPBF
IC GATE DRVR HALF-BRIDGE 14SOIC
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.5V | 1.9A, 2.3A |
