| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN54HC04VTDE2
IC INVERTER 6CH 1-INP DIE
|
54HC | Tube | Active | Inverter | 1 | - | - | - | - | - |
|
CD4069UBEE4
IC INVERTER 6CH 6-INP 14DIP
|
4000B | Tube | Active | Inverter | 6 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1V ~ 2.5V | 4V ~ 12.5V |
|
CD4081BM96G4
IC GATE AND 4CH 2-INP 14SOIC
|
4000B | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
5962-8404501VCA
SPACE 4-CH, 2-INPUT, 2-V TO 6-V
|
54HC | Tube | Active | OR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
5962-9682601Q2A
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54AHCT | Tube | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
SNJ54AHCT08J
IC GATE AND 4CH 2-INP 14CDIP
|
54AHCT | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
JM38510/65204SDA
AND GATE, HC/UH SERIES, 3 FUNC,
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
SNJ54ACT14J
MILITARY 6-CH, 4.5-V TO 5.5-V IN
|
54ACT | Tube | Active | Inverter | 6 | Schmitt Trigger | 4.5V ~ 5.5V | 24mA, 24mA | 1.2V ~ 1.4V | 1.9V ~ 2.1V |
|
|
CD4071BF
MILITARY 4-CH, 2-INPUT, 3-V TO 1
|
4000B | Tube | Active | OR Gate | 2 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
5962-8984502CA
MILITARY 4-CH, 4-INPUT, 2-V TO 6
|
54HC | Tube | Active | NAND Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 1V ~ 3.2V | 1.5V ~ 4.2V |
|
|
M38510/65101B2A
IC GATE NOR 4CH 2-INP 20LCCC
|
54HC | Tube | Active | NOR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
5962-8973401VCA
SPACE 6-CH, 4.5-V TO 5.5-V INVER
|
54ACT | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
