| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
74V1G32STR
IC GATE OR 1CH 2-INP SOT23-5
|
74V | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V | 1.5V |
|
M74HC7266RM13TR
IC GATE XNOR 4CH 2-INP 14SO
|
74HC | Tape & Reel (TR) | Obsolete | XNOR (Exclusive NOR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
74LVQ32MTR
IC GATE OR 4CH 2-INP 14SO
|
74LVQ | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
|
M74HC86RM13TR
IC GATE XOR 4CH 2-INP 14SO
|
74HC | Tape & Reel (TR) | Obsolete | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
HCF4075M013TR
IC GATE OR 3CH 3-INP 14SO
|
4000 | Tape & Reel (TR) | Obsolete | OR Gate | 3 | - | 3V ~ 20V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
M74HC02TTR
IC GATE NOR 4CH 2-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
74VHC20TTR
IC GATE NAND 2CH 4-INP 14TSSOP
|
74VHC | Tape & Reel (TR) | Obsolete | NAND Gate | 4 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V | 1.5V |
|
|
M74HCT00RM13TR
IC GATE NAND 4CH 2-INP 14SO
|
74HCT | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
|
74VHC02TTR
IC GATE NOR 4CH 2-INP 14TSSOP
|
74VHC | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V | 1.5V |
|
|
74VHCT02AMTR
IC GATE NOR 4CH 2-INP 14SO
|
74VHCT | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
74LVX32MTR
IC GATE OR 4CH 2-INP 14SO
|
74LVX | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 2V ~ 3.6V | 4mA, 4mA | 0.5V ~ 0.8V | 1.5V ~ 2.4V |
|
|
74VHC14TTR
IC INVERTER 6CH 1-INP 14TSSOP
|
74VHC | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
