| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AHC04PWRE4
IC INVERTER 6CH 1-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74HCT14QPWRRB
PROTOTYPE
|
74HCT | Bulk | Active | Inverter | 6 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 1.2V ~ 1.4V | 1.9V ~ 2.1V |
|
CD74HCT32EG4
IC GATE OR 4CH 2-INP 14DIP
|
74HCT | Tube | Discontinued at | OR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
CD74HCT132MT
IC GATE NAND 4CH 2-INP 14SOIC
|
74HCT | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
SN74LS03D
IC GATE NAND OPEN 4CH 2IN 14SOIC
|
74LS | Tube | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | 250µA, 16mA | 0.8V | 2V |
|
SN74HCT08NSR
IC GATE AND 4CH 2-INP 14SOP
|
74HCT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74HCT00ANSR
OPEN 98/06/05
|
74HCT | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
|
SN74AHC00BQAR
IC GATE NAND 4CH 2-INP 14WQFN
|
74AHC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
CD74HCT03M
IC GATE NAND OD 4CH 2-INP 14SOIC
|
74HCT | Tube | Discontinued at | NAND Gate | 2 | Open Drain | 4.5V ~ 5.5V | -, 4mA | 0.8V | 2V |
|
CD74HCT08M96
IC GATE AND 4CH 2-INP 14SOIC
|
74HCT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74AHC1G14DRLRG4
IC INVERT SCHMITT 1CH 1-INP SOT5
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74AS10D
IC GATE NAND 3CH 3-INP 14SOIC
|
74AS | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
