| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
MCW100E101
IC GATE OR/NOR QUAD
|
* | Tube | Active | - | - | - | - | - | - | - |
|
74LS20P-E
74LS20 DUAL 4-INPUT NAND GATE
|
* | - | Active | - | - | - | - | - | - | - |
|
|
D74HV1G00VS#H1
IC GATE NAND
|
* | - | Active | - | - | - | - | - | - | - |
|
D74HV1G32VS#H1
IC GATE OR 2-INP
|
* | - | Active | - | - | - | - | - | - | - |
|
|
D74HV1G08VS#H1
IC GATE AND 2-INP
|
* | - | Active | - | - | - | - | - | - | - |
|
|
74LS27P-E
TRIPLE 3-INPUT POS NOR GATES
|
* | - | Active | - | - | - | - | - | - | - |
|
|
74HC1G14CME-E
IC INVERTER 1CH 1-INP CMPAK-6
|
74HC | - | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 2.6mA, 2.6mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
|
CD4081BDMSR
IC
|
4000B | - | Obsolete | AND Gate | 2 | - | 3V ~ 18V | 3.5mA, 3.5mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
CD4081BDNSR
IC LOGIC
|
4000B | - | Obsolete | AND Gate | 2 | - | 3V ~ 18V | 4.2mA, 4.2mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
74HC20FP-E
IC GATE NAND 2CH 4 INP
|
74HC | - | Active | NAND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
74HC11FP-E
IC GATE AND 3CH 3 INP
|
74HC | - | Active | AND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
74HC132FP-E
IC GATE NAND SCHMITT 4CH 2 INP
|
74HC | - | Active | NAND Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
