| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN54ALS30AJ
IC GATE NAND 1CH 8-INP 14CDIP
|
54ALS | Tube | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74AS20NSR
IC GATE NAND 2CH 4-INP 14SOP
|
74AS | Tape & Reel (TR) | Obsolete | NAND Gate | 4 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
SN74H11N
AND GATE, 3-INPUT, TTL, PDIP14
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
SN74LVC1G08QDBVRVS
PROTOTYPE
|
74LVC | Bulk | Active | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AUP1G02DSFR
IC GATE NOR 1CH 2-INP 6SON
|
74AUP | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
|
SN74LVC06ANS
IC INVERTER 6CH 1-INP 14SO
|
74LVC | Tube | Active | Inverter | 1 | Open Drain | 1.65V ~ 3.6V | -, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74ALS15AN
AND GATE, ALS SERIES
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
CD54AC08F3A
MILITARY 4-CH, 2-INPUT, 1.5-V TO
|
54AC | Tube | Active | AND Gate | 2 | - | 1.5V ~ 5.5V | 24mA, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
SN74AUP1G02DPWR
IC GATE NOR 1CH 2-INP 4X2SON
|
74AUP | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
CD4025BPW
IC GATE NOR 3CH 3-INP 14TSSOP
|
4000B | Tube | Active | NOR Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74LVC08AQDRCT
PROTOTYPE
|
74LVC | Bulk | Active | AND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
CD4025BEG4
IC GATE NOR 3CH 3-INP 14DIP
|
4000B | Tube | Discontinued at | NOR Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
