| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
98-0317
IC GATE DRVR HALF-BRIDGE 14SOIC
|
- | Tube | Obsolete | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.9V | 200mA, 350mA |
|
IR2151PBF
IC GATE DRVR HALF-BRIDGE 8DIP
|
- | Tube | Obsolete | Half-Bridge | Synchronous | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | - | 125mA, 250mA |
|
IRS2186SPBF
IC GATE DRVR HI/LOW SIDE 8SOIC
|
- | Bulk | Not For New Designs | High-Side or Low-Side | Independent | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.5V | 4A, 4A |
|
PMC41570AUMA1
IFX POWERSTAGE/DRIVER
|
- | Tape & Reel (TR) | Active | - | - | - | - | - | - | - |
|
|
2ED1322S12MXUMA1
HALF-BRIDGE GATE DRIVER
|
- | Tape & Reel (TR) | Active | - | Independent | 2 | IGBT, SiC MOSFET | 13V ~ 20V | 1.1V, 1.7V | - |
|
IR2153PBF
IC GATE DRVR HALF-BRIDGE 8DIP
|
- | Tube | Not For New Designs | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 10V ~ 15.6V | - | - |
|
IR2135JTRPBF
IC GATE DRVR HALF-BRIDGE 44PLCC
|
- | Tape & Reel (TR) | Active | Half-Bridge | 3-Phase | 6 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.2V | 250mA, 500mA |
|
IRS2124STRPBF
IC GATE DRVR HIGH-SIDE 8SOIC
|
- | Tape & Reel (TR) | Obsolete | High-Side | Single | 1 | IGBT, N-Channel MOSFET | 10V ~ 20V | - | 500mA, 500mA |
|
IRS21531DSPBF
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Bulk | Last Time Buy | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 10V ~ 15.4V | - | 180mA, 260mA |
|
|
IRS26320JPBF
IC GATE DRVR HALF-BRIDGE 44PLCC
|
- | Bulk | Obsolete | Half-Bridge | 3-Phase | 6 | IGBT, N-Channel, P-Channel MOSFET | 12V ~ 20V | - | 200mA, 350mA |
|
IRS2004PBF
IC GATE DRVR HALF-BRIDGE 8DIP
|
- | Tube | Last Time Buy | Half-Bridge | Synchronous | 2 | IGBT, N-Channel MOSFET | 10V ~ 20V | 0.8V, 2.5V | 290mA, 600mA |
|
IRS2118PBF
IC GATE DRVR HIGH-SIDE 8DIP
|
- | Tube | Last Time Buy | High-Side | Single | 1 | IGBT, N-Channel MOSFET | 10V ~ 20V | 6V, 9.5V | 290mA, 600mA |
