| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SM74104SDX/NOPB
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Active | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 9V ~ 14V | 0.8V, 2V | 1.6A, 1.6A |
|
LM5101M
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tube | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 0.8V, 2.2V | 1.6A, 1.6A |
|
SN75372PE4
10-MA/40-MA DUAL-CHANNAL GATE DR
|
- | Tube | Active | Low-Side | Synchronous | 2 | N-Channel MOSFET | - | 0.8V, 2V | 500mA, 500mA |
|
TPIC44H01DAR
IC GATE DRVR HIGH-SIDE 32TSSOP
|
- | Tape & Reel (TR) | Active | High-Side | Independent | 4 | N-Channel MOSFET | 4.5V ~ 5.5V | - | - |
|
LM5102SDX/NOPB
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | IGBT, N-Channel MOSFET | 9V ~ 14V | 0.8V, 2.2V | 1.6A, 1.6A |
|
UC2707DWTR
IC GATE DRVR LOW-SIDE 16SOIC
|
- | Tape & Reel (TR) | Active | Low-Side | Independent | 2 | N-Channel MOSFET | 5V ~ 40V | 0.8V, 2.2V | 1.5A, 1.5A |
|
|
LM2101DR
105-V, 0.5-A/0.8-A HALF-BRIDGE G
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 18V | - | 500mA, 800mA |
|
UCC37324PG4
IC GATE DRVR LOW-SIDE 8DIP
|
- | Tube | Discontinued at | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 15V | 1V, 2V | 4A, 4A |
|
|
LM5109BMAX
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 8V ~ 14V | 0.8V, 2.2V | 1A, 1A |
|
LM5106SD
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 8V ~ 14V | 0.8V, 2.2V | 1.2A, 1.8A |
|
|
LM25101BMAX/NOPB
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 2A, 2A |
|
LM5109BSDX
IC GATE DRVR HALF-BRIDGE 8WSON
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 8V ~ 14V | 0.8V, 2.2V | 1A, 1A |
