| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
TC4425COE
IC GATE DRVR LOW-SIDE 16SOIC
|
- | Tube | Active | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 3A, 3A |
|
TC4422AVOA713
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tape & Reel (TR) | Active | Low-Side | Single | 1 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 10A, 10A |
|
TC4431EPA
IC GATE DRV HI-SIDE/LO-SIDE 8DIP
|
- | Tube | Active | High-Side or Low-Side | Single | 1 | N-Channel, P-Channel MOSFET | 4.5V ~ 30V | 0.8V, 2.4V | 1.5A, 1.5A |
|
TC1428COA713
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tape & Reel (TR) | Active | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 16V | 0.8V, 3V | 1.2A, 1.2A |
|
MCP14E10-E/MF
IC GATE DRVR LOW-SIDE 8DFN
|
- | Tube | Active | Low-Side | Independent | 2 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 3A, 3A |
|
MCP14A0304T-E/MS
IC GATE DRVR HI/LOW SIDE 8MSOP
|
- | Tape & Reel (TR) | Active | High-Side or Low-Side | Independent | 2 | IGBT | 4.5V ~ 18V | 0.8V, 2V | 3A, 3A |
|
MIC4420CM
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tube | Discontinued at | Low-Side | Single | 1 | N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 6A, 6A |
|
|
MIC4452YM-TR
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tape & Reel (TR) | Active | Low-Side | Single | 1 | IGBT, N-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 12A, 12A |
|
|
MIC4422BM
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tube | Discontinued at | Low-Side | Single | 1 | IGBT, N-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 9A, 9A |
|
|
MIC4452VM-TR
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tape & Reel (TR) | Active | Low-Side | Single | 1 | IGBT, N-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 12A, 12A |
|
MCP14A0301T-E/KBA
IC GATE DRVR HI/LOW SIDE 8WDFN
|
- | Tape & Reel (TR) | Active | High-Side or Low-Side | Single | 1 | IGBT | 4.5V ~ 18V | 0.8V, 2V | 3A, 3A |
|
MCP1404T-E/SN
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tape & Reel (TR) | Active | Low-Side | Independent | 2 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 4.5A, 4.5A |
