| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74HC86NSRG4
IC GATE XOR 4CH 2-INP 14SOP
|
74HC | Tape & Reel (TR) | Discontinued at | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC05NG4
IC INVERTER OD 6CH 1-INP 14DIP
|
74HC | Tube | Discontinued at | Inverter | 1 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
54LS27LMQB
NOR GATE, LS SERIES TTL
|
54LS | Bulk | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
SN74HC05DBRE4
IC INVERTER OD 6CH 1-INP 14SSOP
|
74HC | Tape & Reel (TR) | Obsolete | Inverter | 1 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC04DBRG4
IC INVERTER 6CH 1-INP 14SSOP
|
74HC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC7002NSRE4
IC GATE NOR SCHMIT 4CH 2IN 14SOP
|
74HC | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
CD4082BM
IC GATE AND 2CH 4-INP 14SOIC
|
4000B | Tube | Active | AND Gate | 4 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74HC11PWTG4
IC GATE AND 3CH 3-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Obsolete | AND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC04NG4
IC INVERTER 6CH 1-INP 14DIP
|
74HC | Tube | Discontinued at | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
CD4075BPW
IC GATE OR 3CH 3-INP 14TSSOP
|
4000B | Tube | Active | OR Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
CD74HC10MT
IC GATE NAND 3CH 3-INP 14SOIC
|
74HC | Tape & Reel (TR) | Obsolete | NAND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC7002PWT
IC GATE NOR 4CH 2-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Discontinued at | NOR Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
