| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AHC1G08DCKJ
IC GATE AND 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
M38510/05053BCA
IC GATE NAND 3CH 3-INP 14CDIP
|
4000B | Tube | Active | NAND Gate | 3 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
V62/03604-01XE
IC GATE NAND 4CH 2-INP 14SOIC
|
74AHC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
CD4023BE-NG
PROTOTYPE
|
4000B | Bulk | Active | NAND Gate | 3 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
M38510/17103BCA
MILITARY 3-CH, 3-INPUT, 3-V TO 1
|
4000B | Tube | Active | OR Gate | 3 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74HC11DR
IC GATE AND 3CH 3-INP 14SOIC
|
74HC | Tape & Reel (TR) | Active | AND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC04PWR
IC INVERTER 6CH 1-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Active | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
CD4011BM96
IC GATE NAND 4CH 2-INP 14SOIC
|
4000B | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74HC86NSR
IC GATE XOR 4CH 2-INP 14SOP
|
74HC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
CD4023BPW
IC GATE NAND 3CH 3-INP 14TSSOP
|
4000B | Tube | Discontinued at | NAND Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
SN74HCT14DTG4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74HCT | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
|
SN74HCT02APWR
IC GATE NOR 4CH 2-INP 14TSSOP
|
74HCT | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
