| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LVC1G02DBVTG4
IC GATE NOR 1CH 2-INP SOT23-5
|
74LVC | Tape & Reel (TR) | Discontinued at | NOR Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74LVC1G08DCKTE4
IC GATE AND 1CH 2-INP SC70-5
|
74LVC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | - | - |
|
SN74HCT04PWT
IC INVERTER 6CH 1-INP 14TSSOP
|
74HCT | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74LVC2G38DCUTG4
IC GATE NAND OD 2CH 2-INP 8VSSOP
|
74LVC | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | Open Drain | 1.65V ~ 5.5V | -, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74LV00ADRE4
IC GATE NAND 4CH 2-INP 14SOIC
|
74LV | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
HVAL02231ARGYR
MOTOR DRIVER
|
74LVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74LVC2G08DCURE4
IC GATE AND 2CH 2-INP 8VSSOP
|
74LVC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AHCT32QPWR
IC GATE OR 4CH 2-INP 14TSSOP
|
74AHCT | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74HCT32NS
IC GATE NOR 2CH 4-INP 14SOP
|
74HCT | Bulk | Active | OR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.8V | 2V |
|
SN74LVC32ADE4
IC GATE OR 4CH 2-INP 14SOIC
|
74LVC | Tube | Active | OR Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74LVC132ADRQ1
QUADRUPLE POSITIVE-NAND GATES WI
|
74LVC | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 1.1V ~ 3.6V | 24mA, 24mA | 0.6V ~ 1.7V | 0.8V ~ 2V |
|
CD74HCT86ME4
IC GATE XOR 4CH 2-INP 14-SOIC
|
74HCT | Tube | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
