| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
M74HC00B1R
IC GATE NAND 4CH 2-INP 14DIP
|
74HC | Tube | Obsolete | NAND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
74LCX02MTR
IC GATE NOR 4CH 2-INP 14SO
|
74LCX | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
74LX1G14CTR
IC INVERTER 1CH 1-INP SOT323-5
|
74LX | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 1.65V ~ 5.5V | 32mA, 32mA | 0.39V ~ 1.87V | 1.16V ~ 3.33V |
|
|
M74HC4072RM13TR
IC GATE OR 2CH 4-INP 14SO
|
74HC | Tape & Reel (TR) | Obsolete | OR Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
74VHCT05AMTR
IC INVERTER OD 6CH 1-INP 14SO
|
74VHCT | Tape & Reel (TR) | Obsolete | Inverter | 1 | Open Drain | 4.5V ~ 5.5V | -, 8mA | 0.8V | 2V |
|
|
74LVX02MTR
IC GATE NOR 4CH 2-INP 14SO
|
74LVX | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | - | 2V ~ 3.6V | 4mA, 4mA | 0.5V ~ 0.8V | 1.5V ~ 2.4V |
|
74LVX132TTR
IC GATE NAND 4CH 2-INP 14TSSOP
|
74LVX | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | Schmitt Trigger | 2V ~ 3.6V | 4mA, 4mA | 0.9V | 2.2V |
|
|
74LVC04AMTR
IC INVERTER 6CH 1-INP 14SO
|
74LVC | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
HCF4081BEY
IC GATE AND 4CH 2-INP 14DIP
|
4000B | Tube | Obsolete | AND Gate | 2 | - | 3V ~ 20V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
74AC04MTR
IC INVERTER 6CH 1-INP 14SO
|
74AC | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
HCF4070YM013TR
IC GATE XOR 4CH 2-INP 14SO
|
Automotive, AEC-Q100, 4000 | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 3V ~ 20V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
74LVX08TTR
IC GATE AND 4CH 2-INP 14TSSOP
|
74LVX | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 2V ~ 3.6V | 4mA, 4mA | 0.5V ~ 0.8V | 1.5V ~ 2.4V |
