| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
74LX1GU04CTR
IC INVERTER 1CH 1-INP SOT323-5
|
74LX | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 1.65V ~ 5.5V | 32mA, 32mA | - | - |
|
74V2G08STR
IC GATE AND 2CH 2-INP SOT23-8
|
74V | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V | 1.5V |
|
M74HCT14TTR
IC INVERTER 6CH 1-INP 14TSSOP
|
74HCT | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
M74HC05B1R
IC INVERTER OD 6CH 1-INP 14DIP
|
74HC | Tube | Obsolete | Inverter | 1 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
74LX1G00CTR
IC GATE NAND 1CH 2-INP SOT323-5
|
74LX | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | - | - |
|
|
74LVQ32TTR
IC GATE OR 4CH 2-INP 14TSSOP
|
74LVQ | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
|
74VHCU04TTR
IC INVERTER 6CH 1-INP 14TSSOP
|
74VHCU | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.3V | 1.7V |
|
74LVX20MTR
IC GATE NAND 2CH 4-INP 14SO
|
74LVX | Tape & Reel (TR) | Obsolete | NAND Gate | 4 | - | 2V ~ 3.6V | 4mA, 4mA | 0.5V ~ 0.8V | 1.5V ~ 2.4V |
|
|
HCF4025BEY
IC GATE NOR 3CH 3-INP 14DIP
|
4000 | Tube | Obsolete | NOR Gate | 3 | - | 3V ~ 20V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
M74HC86M1R
IC GATE XOR 4CH 2-INP 14SO
|
74HC | Tube | Obsolete | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
74LX1G14STR
IC INVERTER 1CH 1-INP SOT23-5
|
74LX | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 1.65V ~ 5.5V | 32mA, 32mA | 0.39V ~ 1.87V | 1.16V ~ 3.33V |
|
|
M74HCU04TTR
IC INVERTER 6CH 1-INP 14TSSOP
|
74HCU | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.7V ~ 4.8V |
