| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD54HC02F
MILITARY 4-CH, 2-INPUT, 2-V TO 6
|
- | Tube | Active | NOR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74S09NSR
IC GATE AND OP COL 4CH 2IN 14SOP
|
74S | Tape & Reel (TR) | Active | AND Gate | 2 | Open Collector | 4.75V ~ 5.25V | -, 20mA | 0.8V | 2V |
|
SN74AHCT00DG4
IC GATE NAND 4CH 2-INP 14SOIC
|
74AHCT | Tube | Discontinued at | NAND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74S10DE4
IC GATE NAND 3CH 3-INP 14SOIC
|
74S | Tube | Obsolete | NAND Gate | 3 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
|
SN5432J
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
- | Tube | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 16mA | 0.8V | 2V |
|
74S11DC
AND GATE
|
74S | Bulk | Active | AND Gate | 3 | - | 4.75V ~ 5.25V | - | - | - |
|
|
SN74S140D
IC GATE NAND 2CH 4-INP 14SOIC
|
74S | Tube | Active | NAND Gate | 4 | - | 4.75V ~ 5.25V | 40mA, 60mA | 0.8V | 2V |
|
|
M38510/05254BCA
IC GATE NOR 3CH 3-INP 14CDIP
|
- | Tube | Active | NOR Gate | 3 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
74S133DC
NAND GATE, TTL
|
74S | Bulk | Obsolete | NAND Gate | 13 | - | 4.75V ~ 5.25V | 1mA, 20mA | - | - |
|
|
SN74S08DRG4
IC GATE AND 4CH 2-INP 14SOIC
|
74S | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SN74AHCT08RGYR
IC GATE AND 4CH 2-INP 14VQFN
|
74AHCT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74AHCT1G32DBVT
IC GATE OR 1CH 2-INP SOT23-5
|
74AHCT | Tape & Reel (TR) | Discontinued at | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
