| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AHC1G32DCKR
IC GATE OR 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Active | OR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
5962-9759301QDA
MILITARY 6-CH, 4.5-V TO 5.5-V BI
|
54F | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74AHC1G04DBVRE4
IC INVERTER 1CH 1-INP SOT23-5
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC1G08DBVR
IC GATE AND 1CH 2-INP SOT23-5
|
74AHC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC05PWR
IC INVERTER OD 6CH 1-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Active | Inverter | 1 | Open Drain | 2V ~ 5.5V | -, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC14PWE4
IC INVERTER 6CH 1-INP 14TSSOP
|
74AHC | Tube | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74AHC32PW
IC GATE OR 4CH 2-INP 14TSSOP
|
74AHC | Tube | Discontinued at | OR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC00MPWREP
IC GATE NAND 4CH 2-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
SN74AHC1G00DCKTG4
IC GATE NAND 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC02N
IC GATE NOR 4CH 2-INP 14DIP
|
74AHC | Tube | Active | NOR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC02PWRE4
IC GATE NOR 4CH 2-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Discontinued at | NOR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
SN74AHC1G32DCKTG4
IC GATE OR 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Discontinued at | OR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
