| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LV14APWR-P
PROTOTYPE
|
74LV | Bulk | Active | Inverter | 6 | Schmitt Trigger | 2V ~ 5.5V | 12mA, 12mA | 0.75V ~ 1.5V | 1.75V ~ 3.5V |
|
SN74HC05APWRG4
IC INVERTER OD 6CH 1-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Obsolete | Inverter | 1 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
M38510/30009BDA
MILITARY SINGLE 8-INPUT, 4.5-V T
|
54LS | Tube | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
CD74ACT08M96
IC GATE AND 4CH 2-INP 14SOIC
|
74ACT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
SN74AHC1G04DBVR
IC INVERTER 1CH 1-INP SOT23-5
|
74AHC | Tape & Reel (TR) | Active | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
M38510/30203B2A
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54LS | Tube | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | -, 12mA | 0.7V | 2V |
|
SN74HC11DBR
IC GATE AND 3CH 3-INP 14SSOP
|
74HC | Tape & Reel (TR) | Obsolete | AND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74ACT10NSRE4
IC GATE NAND 3CH 3-INP 14SOP
|
74ACT | Tape & Reel (TR) | Obsolete | NAND Gate | 3 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
SN74AHC1G86DCKTG4
IC GATE XOR 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Discontinued at | XOR (Exclusive OR) | 2 | Schmitt Trigger Input | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
CD74HC86EG4
IC GATE XOR 4CH 2-INP 14DIP
|
74HC | Tube | Discontinued at | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
SN74ACT11DRG4
IC GATE AND 3CH 3-INP 14SOIC
|
74ACT | Tape & Reel (TR) | Discontinued at | AND Gate | 3 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
SN74AHC1GU04DCKT
IC INVERTER 1CH 1-INP SC70-5
|
74AHC | Tape & Reel (TR) | Active | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.3V ~ 1.1V | 1.7V ~ 4.4V |
