| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54AC08FK
MILITARY 4-CH, 2-INPUT, 2-V TO 6
|
54AC | Tube | Active | AND Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74AHC14DRE4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74AHC86N
IC GATE XOR 4CH 2-INP 14DIP
|
74AHC | Tube | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74LV20APWT
IC GATE NAND 2CH 4-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Obsolete | NAND Gate | 4 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
54F32FMQB
QUAD 2-INPUT OR GATE
|
54F | Bulk | Obsolete | OR Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
M38510/30502B2A
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54LS | Tube | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
SN74LV14ANSR-P
PROTOTYPE
|
74LV | Bulk | Active | Inverter | 6 | Schmitt Trigger | 2V ~ 5.5V | 12mA, 12mA | 0.75V ~ 1.5V | 1.75V ~ 3.5V |
|
|
M38510/33301B2A
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54F | Tube | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74AHC1G04DCKTE4
IC INVERTER 1CH 1-INP SC70-5
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC1G86DBVR
IC GATE XOR 1CH 2-INP SOT23-5
|
74AHC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | Schmitt Trigger Input | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
SN74LV6T06BQAR
IC INVERTER 6CH 6-INP 14WQFN
|
74LV | Tape & Reel (TR) | Active | Inverter | 6 | Open Drain | 1.65V ~ 5.5V | -, 8mA | 0.5V ~ 0.85V | 1.1V ~ 2V |
|
|
5962-9758101QDA
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54F | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
