| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74F08DBR
IC GATE AND 4CH 2-INP 14SSOP
|
74F | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SNJ54S00W
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54S | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
DM54S04J/883
INVERTER, S SERIES, 6-FUNC, TTL
|
54S | Bulk | Active | Inverter | 1 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
5962-8684201VCA
PROTOTYPE
|
54ALS | Bulk | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | - |
|
|
JM38510/07002BCA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54S | Tube | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 250µA, 20mA | 0.8V | 2V |
|
|
M38510/37301BCA
IC GATE NOR 4CH 2-INP 14CDIP
|
54ALS | Tube | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
|
SN54S37J
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54S | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 3mA, 60mA | 0.8V | 2V |
|
54S134FM
NAND GATE
|
54S | Bulk | Active | NAND Gate | 12 | 3-State | 4.5V ~ 5.5V | 2mA, - | - | - |
|
|
M38510/37002B2A
IC GATE NAND 3CH 3-INP 20LCCC
|
54ALS | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
|
SNJ54ALS27AJ
IC GATE NOR 3CH 3-INP 14CDIP
|
54ALS | Tube | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
|
SN54ALS11AJ
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54ALS | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
|
SNJ54ALS09J
IC GATE AND 4CH 2-INP 14CDIP
|
54ALS | Tube | Active | AND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 100µA, 4mA | 0.8V | 2V |
