| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74F08N
IC GATE AND 4CH 2-INP 14DIP
|
74F | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74F86NSR
IC GATE XOR 4CH 2-INP 14SOP
|
74F | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
JM38510/07009BEA
NAND GATE, 13-INPUT
|
54S | Bulk | Active | NAND Gate | 13 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74F38NSRE4
IC GATE NAND OPEN 4CH 2-IN 14SOP
|
74F | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | -, 64mA | 0.8V | 2V |
|
M38510/07003BDA
IC INVERTER 6CH 6-INP 14CFP
|
54S | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74F21DRE4
IC GATE AND 2CH 4-INP 14SOIC
|
74F | Tape & Reel (TR) | Discontinued at | AND Gate | 4 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
DM54S140J-MIL
NAND GATE, TTL
|
54S | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 3mA, 60mA | 0.8V | 2V |
|
SN74F04DR
IC INVERTER 6CH 1-INP 14SOIC
|
74F | Tape & Reel (TR) | Active | Inverter | 1 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74F08DBR
IC GATE AND 4CH 2-INP 14SSOP
|
74F | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
SNJ54S132W
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54S | Tube | Active | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 1mA, 20mA | 1.4V | 1.9V |
|
|
SNJ54S04W
MILITARY 6-CH, 4.5-V TO 5.5-V BI
|
54S | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
SN54ALS21AJ
MILITARY 2-CH, 4-INPUT, 4.5-V TO
|
54ALS | Tube | Active | AND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
