| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
M38510/08001BDA
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54S | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
1P1G08MDBVREPG4
IC GATE AND 1CH 2-INP SOT23-5
|
- | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
CD74HC4075PW
IC GATE OR 3CH 3-INP 14TSSOP
|
74HC | Tube | Discontinued at | OR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74AHCT132PWRG4
IC GATE NAND 4CH 2-INP 14TSSOP
|
74AHCT | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
SN74HCS03DR
IC LOGIC GATES
|
74HCS | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger, Open Drain | 2V ~ 6V | -, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
SN74HC04PW
IC INVERTER 6CH 1-INP 14TSSOP
|
74HC | Tube | Discontinued at | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HCS20PWR
IC GATE NAND 2CH 4-INP 14TSSOP
|
74HCS | Tape & Reel (TR) | Active | NAND Gate | 4 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
|
JM38510/07501BCA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54S | Tube | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HCS32DYYR
QUADRUPLE 2-INPUT OR GATES WITH
|
74HCS | Tape & Reel (TR) | Active | OR Gate | 2 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
|
5962-8859001FA
MILITARY SINGLE 13-INPUT, 4.5-V
|
54ALS | Tube | Active | NAND Gate | 13 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74AHCT08PW
IC GATE AND 4CH 2-INP 14TSSOP
|
74AHCT | Tube | Discontinued at | AND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
SN74AHCT14PW-P
PROTOTYPE
|
74AHCT | Bulk | Active | Inverter | 6 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | - | 1.9V ~ 2.1V |
