| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN7438NSR
IC GATE NAND OPEN 4CH 2-IN 14SOP
|
7400 | Tape & Reel (TR) | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | -, 48mA | 0.8V | 2V |
|
SNJ54F09J
AND GATE, F/FAST SERIES, TTL
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LV1T04DBVRG4
IC INVERTER 1CH 1-INP SOT23-5
|
74LV | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 1.6V ~ 5.5V | 8mA, 8mA | 0.58V ~ 0.8V | 0.94V ~ 2.1V |
|
74AC11004DWR
IC INVERTER 6CH 1-INP 20SOIC
|
74AC | Tape & Reel (TR) | Active | Inverter | 1 | - | 3V ~ 5.5V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN7400D
IC GATE NAND 4CH 2-INP 14SOIC
|
7400 | Tube | Active | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
74ACT11132D
NAND GATE, ACT SERIES
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LV08APWTG4
IC GATE AND 4CH 2-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
SN74LVC1G125DCKR-P
PROTOTYPE
|
74LVC | Bulk | Active | - | - | - | - | - | - | - |
|
SN74AC00DBRG4
IC GATE NAND 4CH 2-INP 14SSOP
|
74AC | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
SN74LV14APW-P
PROTOTYPE
|
74LV | Bulk | Active | Inverter | 6 | Schmitt Trigger | 2V ~ 5.5V | 12mA, 12mA | 0.75V ~ 1.5V | 1.75V ~ 3.5V |
|
SN74LVC132ADR
QUADRUPLE POSITIVE-NAND GATES WI
|
74LVC | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 1.1V ~ 3.6V | 24mA, 24mA | 0.6V ~ 1.7V | 0.8V ~ 2V |
|
|
SN74AC04PWRG4
IC INVERTER 6CH 1-INP 14TSSOP
|
74AC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
