| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Circuits | Number of Inputs | Schmitt Trigger Input | Output Type | Current - Output High, Low | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
JM38510/07401BCA
SN54S51 AND-OR-INVERT GATES
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LVC3G97PWR
THREE-CHANNEL 1.1V-TO-3.6V MULTI
|
74LVC | Tape & Reel (TR) | Active | Configurable Multiple Function | 1 | 3 | Yes | Single-Ended | 24mA, 24mA | 1.1V ~ 3.6V |
|
SNJ54LS54J
4-WIDE AND-OR-INVERT GATES 14-CD
|
54LS | Tube | Active | AND/OR/INVERT Gate | 1 | 10 Input (2, 3, 3, 2) | No | Single-Ended | 4mA, 400µA | 4.5V ~ 5.5V |
|
|
SNJ5450W
DUAL 2-WIDE 2-INPUT AND-OR-INVER
|
- | Tube | Active | AND/OR/INVERT Gate | 2 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 16mA, 400µA | 4.5V ~ 5.5V |
|
CD4086BPWRG4
IC EXPND AND-ORINV GATE 14-TSSOP
|
4000B | Tape & Reel (TR) | Obsolete | AND/OR/INVERT Gate | 1 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
SN74LVC2G100BQBR
TWO-CHANNEL 1.1V-TO-3.6V CONFIGU
|
- | - | - | - | - | - | - | - | - | - |
|
CD4085BNSRE4
IC DUAL AND-ORINV GATE 14SO
|
4000B | Tape & Reel (TR) | Obsolete | AND/OR/INVERT Gate | 2 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
JM38510/00501BCA
DUAL 2-WIDE 2-INPUT AND-OR-INVER
|
- | Tube | Active | AND/OR/INVERT Gate | 2 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 16mA, 400µA | 4.5V ~ 5.5V |
|
|
SN74LVC3G98WBQARQ1
AUTOMOTIVE, 3-CHANNEL 1.2V-TO-3.
|
- | - | - | - | - | - | - | - | - | - |
|
|
SN5450J
DUAL 2-WIDE 2-INPUT AND-OR-INVER
|
- | Tube | Active | AND/OR/INVERT Gate | 2 | 8 Input (2, 2, 2, 2) | No | Single-Ended | 16mA, 400µA | 4.5V ~ 5.5V |
|
|
CD4019BF
CMOS QUAD AND/OR SELECT GATE 16-
|
- | Tube | Active | AND/OR Gate | 4 | 2 | No | Single-Ended | 6.8mA, 6.8mA | 3V ~ 18V |
|
|
SNJ54S64J
4-2-3-2 INPUT AND-OR-INVERT GATE
|
54S | Tube | Active | AND/OR/INVERT Gate | 1 | 11 Input (4, 2, 3, 2) | No | Single-Ended | 20mA, 1mA | 4.5V ~ 5.5V |
