| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
LM5101ASDX-1/NOPB
IC GATE DRVR HALF-BRIDGE 8WSON
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 3A, 3A |
|
LM25101ASD/NOPB
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 3A, 3A |
|
UC2706DW
IC GATE DRVR LOW-SIDE 16SOIC
|
- | Bulk | Active | Low-Side | Independent | 2 | N-Channel MOSFET | 5V ~ 40V | 0.8V, 2.2V | 1.5A, 1.5A |
|
UCC27423P
IC GATE DRVR LOW-SIDE 8DIP
|
- | Bulk | Active | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4V ~ 15V | 1V, 2V | 4A, 4A |
|
UCC27323DR
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tape & Reel (TR) | Active | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 15V | 1V, 2V | 4A, 4A |
|
LM5113TMX/NOPB
IC GATE DRVR HALF-BRIDGE 12USMD
|
- | Tape & Reel (TR) | Not For New Designs | Half-Bridge | Independent | 2 | N-Channel MOSFET | 4.5V ~ 5.5V | 1.76V, 1.89V | 1.2A, 5A |
|
LM5106MM
IC GATE DRVR HALF-BRIDGE 10VSSOP
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 8V ~ 14V | 0.8V, 2.2V | 1.2A, 1.8A |
|
|
LM5101MX/NOPB
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tape & Reel (TR) | Not For New Designs | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 0.8V, 2.2V | 1.6A, 1.6A |
|
LM5111-4MYX/NOPB
IC GATE DRVR LOW-SIDE 8MSOP
|
- | Tape & Reel (TR) | Discontinued at | Low-Side | Independent | 2 | N-Channel MOSFET | 3.5V ~ 14V | 0.8V, 2.2V | 3A, 5A |
|
UCC27324DGNG4
IC GATE DRVR LOW-SIDE 8MSOP
|
- | Tube | Discontinued at | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 15V | 1V, 2V | 4A, 4A |
|
LM25101BMA/NOPB
LM25101 3A, 2A AND 1A HIGH VOLTA
|
- | Bulk | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 2A, 2A |
|
TPIC46L03DB
IC GATE DRVR LOW-SIDE 28SSOP
|
- | Tube | Obsolete | Low-Side | Independent | 6 | N-Channel MOSFET | 4.5V ~ 5.5V | - | 1.2mA, 1.2mA |
