| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54LS14FK
IC INVERT SCHMITT 6CH 6IN 20LCCC
|
54LS | Tube | Active | Inverter | 6 | Schmitt Trigger | 4.5V ~ 5.5V | 400µA, 4mA | 1V | 1.9V |
|
SN74LS30N
IC GATE NAND 1CH 8-INP 14DIP
|
74LS | Tube | Active | NAND Gate | 8 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74HCT08ANSR
IC GATE AND 4CH 2-INP 14SO
|
74HCT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.1V ~ 0.26V | 3.98V ~ 4.4V |
|
|
SN74AHC32N-P2
PROTOTYPE
|
74AHC | Bulk | Active | OR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
SN74AS02NS
IC GATE NOR 4CH 2-INP 14SO
|
74AS | Tube | Last Time Buy | NOR Gate | 2 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
|
SNJ54LS37W
IC GATE NAND 4CH 2-INP 14CFP
|
54LS | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1.2mA, 12mA | 0.7V | 2V |
|
CD40106BE
IC INVERT SCHMITT 6CH 1-IN 14DIP
|
4000B | Tube | Active | Inverter | 1 | Schmitt Trigger | 3V ~ 18V | 3.4mA, 3.4mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
SN74LS32D
IC GATE OR 4CH 2-INP 14SOIC
|
74LS | Tube | Discontinued at | OR Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
|
SN54HC08J
AND Gate, HC/UH Series, 4-Func,
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
SN74HCT00APWR
IC GATE NAND 4CH 2-INP 14TSSOP
|
74HCT | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74S86NSRE4
IC GATE XOR 4CH 2-INP 14SOP
|
74S | Tape & Reel (TR) | Obsolete | XOR (Exclusive OR) | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SN74HCS09QDRQ1
IC GATE AND 4CH 2IN 14SOIC
|
Automotive, AEC-Q100, 74HCS | Tape & Reel (TR) | Active | AND Gate | 2 | Schmitt Trigger, Open Drain | 2V ~ 6V | -, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
