| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LS32DE4
IC GATE OR 4CH 2-INP 14SOIC
|
74LS | Tube | Discontinued at | OR Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN54AC00VTD2
IC GATE NAND 4CH 2-INP DIE
|
- | Tube | Active | NAND Gate | 2 | - | 2V ~ 6V | - | - | - |
|
SN74LS266NSR
IC GATE XNOR OPEN 4CH 2-IN 14SOP
|
74LS | Tape & Reel (TR) | Obsolete | XNOR (Exclusive NOR) | 2 | Open Collector | 4.75V ~ 5.25V | -, 8mA | 0.8V | 2V |
|
|
M38510/31001BCA
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54LS | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
SNJ54LS10FK
IC GATE NAND 3CH 3-INP 20LCCC
|
54LS | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
SN74HCS86BQAR
QUADRUPLE 2-INPUT XOR GATES WITH
|
74HCS | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
SN74LS19ADG4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74LS | Tube | Obsolete | Inverter | 1 | Schmitt Trigger | 4.75V ~ 5.25V | 400µA, 8mA | 0.75V | 2.15V |
|
SN74HCS08BQAR
QUADRUPLE 2-INPUT POSITIVE-AND G
|
74HCS | Tape & Reel (TR) | Active | AND Gate | 2 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
SN74LS08DBR
IC GATE AND 4CH 2-INP 14SSOP
|
74LS | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74LVC02AQPWRG4Q1
IC GATE NOR 4CH 2-INP 14TSSOP
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
|
SN54LS00J
IC GATE NAND 4CH 2-INP 14CDIP
|
54LS | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
8404701CA
MILITARY 4-CH, 2-INPUT, 2-V TO 6
|
- | Tube | Active | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
