| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD74HCT03M
IC GATE NAND OD 4CH 2-INP 14SOIC
|
74HCT | Tube | Discontinued at | NAND Gate | 2 | Open Drain | 4.5V ~ 5.5V | -, 4mA | 0.8V | 2V |
|
CD74HCT08M96
IC GATE AND 4CH 2-INP 14SOIC
|
74HCT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74AHC1G14DRLRG4
IC INVERT SCHMITT 1CH 1-INP SOT5
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74AS10D
IC GATE NAND 3CH 3-INP 14SOIC
|
74AS | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
M38510/30501BDA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54LS | Tube | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
SN74AS27D
IC GATE NOR 3CH 3-INP 14SOIC
|
74AS | Tube | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
|
SN74AHC1G08SDCKRWB
PROTOTYPE
|
74AHC | Bulk | Active | AND Gate | 2 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AS804BDWRG4
IC GATE NAND 6CH 2-INP 20SOIC
|
74AS | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 4.5V ~ 5.5V | 48mA, 48mA | 0.8V | 2V |
|
SN74LS14NSR
IC INVERT SCHMITT 6CH 1-IN 14SOP
|
74LS | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 4.75V ~ 5.25V | 400µA, 8mA | 0.5V | 1.9V |
|
|
SNJ54LS02J
IC GATE NOR 4CH 2-INP 14CDIP
|
54LS | Tube | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
74LS15PC
AND GATE, TTL, PDIP14
|
74LS | Bulk | Active | AND Gate | 3 | Open Collector | 4.75V ~ 5.25V | 100µA, 8mA | 0.8V | 2V |
|
SN74HCT08NS
IC GATE NOR 2CH 4-INP 14SOP
|
74HCT | Bulk | Active | AND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.8V | 2V |
