| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
MM54HC32J
OR GATE, HC/UH SERIES
|
54HC | Bulk | Active | OR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
74F32SCX-NS
OR GATE, F/FAST SERIES, 4 FUNC,
|
74F | Bulk | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
JD54L00BDA
IC GATE NAND QUAD 2-INP
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
JM54AC32S2A-RH
54AC32 - QUAD 2-INPUT OR GATE -
|
54AC | Bulk | Active | OR Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
54ALS11AW/883
IC GATE AND
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
DM54S10W/883
NAND GATE
|
- | Bulk | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
JM38510/07008BDA-NS
NAND GATE, 8-INPUT
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
54LS11DM
AND GATE, TTL
|
54LS | Bulk | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
54ALS20AW/883
IC GATE NAND
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
949DC
IC GATE NAND
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
MM54C02W/883
NOR GATE SERIES, 4-FUNC
|
54C | Bulk | Active | NOR Gate | 2 | - | 3V ~ 15V | 360µA, 360µA | 1.5V ~ 2V | 3.5V ~ 8V |
|
|
74F27PC
NOR GATE
|
74F | Bulk | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 20mA, 1mA | 0.8V | 2V |
