| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LS20NE4
2-CH, 4-INPUT, 4.75-V TO 5.25-V
|
74LS | Tube | Active | NAND Gate | 4 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
|
CD4049UBNS
IC INVERTER 6CH 6-INP 16SO
|
- | Tube | Discontinued at | Inverter | 6 | - | 3V ~ 18V | 8mA, 48mA | 1V ~ 2.5V | 4V ~ 12.5V |
|
SN74AHC05PWE4
IC INVERTER HEX W/OD OUT 14TSSOP
|
74AHC | Tube | Active | Inverter | 1 | Open Drain | 2V ~ 5.5V | -, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74HCT02D
IC GATE NOR 4CH 2-INP 14SOIC
|
74HCT | Tube | Discontinued at | NOR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74LS20NSR
IC GATE NAND 2CH 4-INP 14SOP
|
74LS | Tape & Reel (TR) | Active | NAND Gate | 4 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74LVC1G08DRLR
IC GATE AND 1CH 2-INP SOT5
|
74LVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | - | - |
|
|
SN74AHC14DRG4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74LVC06APW
IC INVERTER OD 6CH 1-INP 14TSSOP
|
74LVC | Tube | Active | Inverter | 1 | Open Drain | 1.65V ~ 3.6V | -, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN54HC4002J
54HC4002 DUAL 4-INPUT POSITIVE-N
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
SN74AHC04QPWRG4
IC INVERTER 6CH 1-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
SN74LVC1GU04DRLR
IC INVERTER 1CH 1-INP SOT5
|
74LVC | Tape & Reel (TR) | Active | Inverter | 1 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.41V ~ 1.38V | 1.24V ~ 4.13V |
|
SNJ54AS11J
54AS11 TRIPLE 3-INPUT POSITIVE-A
|
* | Bulk | Active | - | - | - | - | - | - | - |
