| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
74LS132PC
NAND GATE, LS SERIES TTL
|
74LS | Bulk | Active | NAND Gate | 2 | Schmitt Trigger | 4.75V ~ 5.25V | 400µA, 8mA | 1V | 1.9V |
|
100102FCQL
OR/NOR GATE, 100K SERIES
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
SNJ54ALS27AW
54ALS27A TRIPLE 3-INPUT POSITIVE
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74HCT02PWR
IC GATE NOR 4CH 2-INP 14TSSOP
|
74HCT | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74S10NS
IC GATE NAND 3CH 3-INP 14-SO
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
100121FC
INVERTER, 100K SERIES
|
- | Bulk | Active | Inverter | 9 | - | 4.2V ~ 5.7V | - | 1.49V | 0.88V |
|
SN74LS00NS
IC GATE NAND 4CH 2-INP 14SO
|
74LS | Tube | Discontinued at | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74AHC08PWRE4
IC GATE AND 4CH 2-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
SN74LS00NE4
4-CH, 2-INPUT, 4.75-V TO 5.25-V
|
74LS | Tube | Active | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
CD74HCT03MT
IC GATE NAND OD 4CH 2-INP 14SOIC
|
74HCT | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | Open Drain | 4.5V ~ 5.5V | -, 4mA | 0.8V | 2V |
|
SN74AHC14RGYR
IC INV SCHMITT 6CH 1-IN 14VQFN
|
74AHC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74HCT08N
IC GATE AND 4CH 2-INP 14DIP
|
74HCT | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
