| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74HC10NSR
IC GATE NAND 3CH 3-INP 14SOP
|
74HC | Tape & Reel (TR) | Active | NAND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LV11APWR
IC GATE AND 3CH 3-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Active | AND Gate | 3 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
SN74HC08ADB
IC GATE AND 4CH 2-INP 14SSOP
|
74HC | Bulk | Active | AND Gate | 2 | - | 2V ~ 6V | 4mA, 4mA | 0.1V ~ 0.26V | 1.9V ~ 5.9V |
|
JM38510/33001B2A
54F00 QUADRUPLE 2-INPUT POSITIVE
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LVC2G38YZPR
IC GATE NAND OD 2CH 2-INP 8DSBGA
|
74LVC | Tape & Reel (TR) | Active | NAND Gate | 2 | Open Drain | 1.65V ~ 5.5V | -, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
CD4070BPWR
IC GATE XOR 4CH 2-INP 14TSSOP
|
4000B | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74HC14ANSR
IC INVERT SCHMITT 6CH 1-INP 14SO
|
74HC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.1V ~ 0.26V | 1.9V ~ 5.9V |
|
SN74AHCT1G86DCKR
IC GATE XOR 1CH 2-INP SC70-5
|
74AHCT | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74LV14ARGYR
IC INV SCHMITT 6CH 1-IN 14VQFN
|
74LV | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 12mA, 12mA | 0.75V ~ 1.5V | 1.75V ~ 3.5V |
|
SNJ54LS21FK
54LS21 DUAL 4-INPUT POSITIVE-AND
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LVC08ADB
IC GATE AND 4CH 2-INP 14-SSOP
|
74LVC | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LV02ADGVR
IC GATE NOR 4CH 2-INP 14TVSOP
|
74LV | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
