| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DM54LS11J/883
AND GATE, LS SERIES
|
54LS | Bulk | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
7403PC
IC GATE NAND 4CH 2-INP 14DIP
|
- | Bulk | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | - | - | - |
|
74VHCT04MTCX
INVERTER, AHCT/VHCT SERIES, 6-FU
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
54S40DM
NAND GATE, TTL
|
54S | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 60mA | 0.8V | 2V |
|
|
54H30DM
IC GATE NAND 1CH 8-INP 14CERDIP
|
54H | Bulk | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | - | - | - |
|
|
949DM
IC GATE NAND
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
4019BDC
IC GATE OR
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
9504DC
IC GATE NOR
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
JD54F00SDA
IC GATE NAND 4CH 2-INP 14CFP
|
54F | Bulk | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
9016DC
IC GATE NAND 2CH 4-INP 14CDIP
|
- | Bulk | Active | NAND Gate | 4 | - | 4.75V ~ 5.25V | 1.2mA, 16mA | 0.85V | 1.8V |
|
|
JD9946BDA
IC
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
JD54LS27BDA
IC GATE NOR TRPL 3-INP
|
* | Bulk | Active | - | - | - | - | - | - | - |
