| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74HC86PWR
IC GATE XOR 4CH 2-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
CD4073BNSR
IC GATE AND 3CH 3-INP 14SOP
|
4000B | Tape & Reel (TR) | Active | AND Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
CD74HC11E
IC GATE AND 3CH 3-INP 14DIP
|
74HC | Tube | Active | AND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
CD4072BPWRE4
IC GATE OR 2CH 4-INP 14TSSOP
|
4000B | Tape & Reel (TR) | Obsolete | OR Gate | 4 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74F38DG4
IC GATE NAND OPEN 4CH 2IN 14SOIC
|
74F | Tube | Obsolete | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | -, 64mA | 0.8V | 2V |
|
CD4077BPWRE4
IC GATE XNOR 4CH 2-INP 14TSSOP
|
4000B | Tape & Reel (TR) | Obsolete | XNOR (Exclusive NOR) | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74ALVC10D
IC GATE NAND 3CH 3-INP 14SOIC
|
74ALVC | Tube | Active | NAND Gate | 3 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
54S86FM
XOR GATE, TTL
|
54S | Bulk | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | - | - | - |
|
SN74F32NE4
4-CH, 2-INPUT, 4.5-V TO 5.5-V BI
|
74F | Tube | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
CD4069UBNS
MEMORY
|
4000B | Tape & Reel (TR) | Discontinued at | Inverter | 6 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1V ~ 2.5V | 4V ~ 12.5V |
|
|
SN74F00D
IC GATE NAND 4CH 2-INP 14SOIC
|
74F | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
JM38510/17101BCA
MILITARY 4-CH, 2-INPUT, 3-V TO 1
|
4000B | Tube | Active | OR Gate | 2 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
