| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD4071BM
IC GATE OR 4CH 2-INP 14SOIC
|
4000B | Tube | Discontinued at | OR Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
CD74HC03M
IC GATE NAND OD 4CH 2-INP 14SOIC
|
74HC | Tube | Active | NAND Gate | 2 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
CD40107BPW
IC GATE NAND OD 2CH 2-INP 8TSSOP
|
4000B | Tube | Active | NAND Gate | 2 | Open Drain | 3V ~ 18V | -, 68mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74LVC14ADBRG4
IC INV SCHMITT 6CH 1-IN 14SSOP
|
74LVC | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 1.65V ~ 3.6V | 24mA, 24mA | 0.15V ~ 0.8V | 1.3V ~ 2V |
|
CD4011UBPWR
IC GATE NAND 4CH 2-INP 14TSSOP
|
4000B | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1V ~ 2.5V | 4V ~ 12.5V |
|
SN74HC132DBR
IC GATE NAND 4CH 2-INP 14SSOP
|
74HC | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
SN74LVC00APWRE4
IC GATE NAND 4CH 2-INP 14TSSOP
|
74LVC | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74HC08APWR
IC GATE AND 4CH 2-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 6V | 4mA, 4mA | 0.1V ~ 0.26V | 1.9V ~ 5.9V |
|
SN74HC00AN
IC GATE NAND 4CH 2-INP 14DIP
|
74HC | Bulk | Active | NAND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.1V ~ 0.26V | 1.9V ~ 5.9V |
|
SN74HC04ANSR
IC INVERTER 6CH 1-INP 14SOP
|
74HC | Tape & Reel (TR) | Active | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
CD4011UBPWE4
IC GATE NAND 4CH 2-INP 14TSSOP
|
4000B | Tube | Obsolete | NAND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1V ~ 2.5V | 4V ~ 12.5V |
|
SN74HC05IDRCT
IC INVERTER OD 6CH 1-INP 14SOIC
|
74HC | Bulk | Active | Inverter | 1 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
