| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
54LS37FMQB
NAND GATE, LS SERIES TTL
|
54LS | Bulk | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1.2mA, 12mA | 0.7V | 2V |
|
SNJ54AHC04FK
MILITARY 6-CH, 2-V TO 5.5-V INVE
|
54AHC | Tube | Active | Inverter | 6 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
M38510/30003SCA
SPACE 6-CH, 4.5-V TO 5.5-V BIPOL
|
54LS | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
5962-9680301QDA
MILITARY 6-CH, 2-V TO 5.5-V INVE
|
54AHC | Tube | Active | Inverter | 6 | - | 2V ~ 5.5V | 8mA, 8mA | 0.3V ~ 1.1V | 1.7V ~ 4.4V |
|
|
54LS04FMQB
INVERTER, LS SERIES
|
54LS | Bulk | Active | Inverter | 1 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
CAHCT1G14QDCKRQ1
IC INVERT SCHMITT 1CH 1IN SC70-5
|
Automotive, AEC-Q100, 74AHCT | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 3V ~ 5.5V | 8mA, 8mA | 0.53V ~ 0.8V | 1.4V ~ 2V |
|
SN74LVCU04ADT
IC INVERTER 6CH 1-INP 14SOIC
|
74LVCU | Tape & Reel (TR) | Active | Inverter | 1 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.4V ~ 0.65V | 1.32V ~ 2.88V |
|
|
SN74AHCT08QWBQARQ1
IC GATE AND 4CH 2-INP 14WQFN
|
Automotive, AEC-Q100, 74AHCT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
M38510/31004BCA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54LS | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
CAHCT1G08QDCKRQ1
IC GATE AND 1CH 2-INP SC70-5
|
Automotive, AEC-Q100, 74AHCT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
5962-9754101QDA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54LS | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1.2mA, 12mA | 0.7V | 2V |
|
|
CD54HCT132F3A
MILITARY SINGLE 8-INPUT, 4.5-V T
|
54HCT | Tube | Active | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 1.2V ~ 1.4V | 1.9V ~ 2.1V |
