| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LV4T00QWBQARQ1
IC GATE NAND 4CH 2-INP 14WQFN
|
Automotive, AEC-Q100 | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 1.6V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.85V | 1.1V ~ 2V |
|
SN74ALVC00IDRQ1
IC GATE NAND 4CH 2-INP 14SOIC
|
Automotive, AEC-Q100, 74ALVC | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
CD4011BEE4
4-CH, 2-INPUT, 3-V TO 18-V NAND
|
4011B | Tube | Active | NAND Gate | 2 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74AHCU04PWRG4
IC INVERTER 6CH 1-INP 14TSSOP
|
74AHCU | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.3V ~ 1.1V | 1.7V ~ 4.4V |
|
SN74AC14QPWRQ1
IC INVERTER 6CH 1-INP 14TSSOP
|
Automotive, AEC-Q100, 74AC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 24mA, 24mA | 0.5V ~ 1.1V | 2.2V ~ 3.9V |
|
CD74AC02ME4
IC GATE NOR 4CH 2-INP 14SOIC
|
74AC | Tube | Discontinued at | NOR Gate | 2 | - | 1.5V ~ 5.5V | 24mA, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
SN74ACT00TDRQ1
IC GATE NAND 4CH 2-INP 14SOIC
|
Automotive, AEC-Q100, 74ACT | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
54LS37FMQB
NAND GATE, LS SERIES TTL
|
54LS | Bulk | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1.2mA, 12mA | 0.7V | 2V |
|
|
SN74LVCU04APWR
IC INVERTER 6CH 1-INP 14TSSOP
|
74LVCU | Tape & Reel (TR) | Active | Inverter | 1 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.4V ~ 0.65V | 1.32V ~ 2.88V |
|
SN74AHCU04DE4
IC INVERTER 6CH 1-INP 14SOIC
|
74AHCU | Bulk | Active | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.3V ~ 1.1V | 1.7V ~ 4.4V |
|
SN74AC11IPWRQ1
IC GATE AND 3CH 3-INP 14TSSOP
|
Automotive, AEC-Q100, 74AC | Tape & Reel (TR) | Obsolete | AND Gate | 3 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74LVCU04ADBR
IC INVERTER 6CH 1-INP 14SSOP
|
74LVCU | Tape & Reel (TR) | Active | Inverter | 1 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.4V ~ 0.65V | 1.32V ~ 2.88V |
