| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
M38510/33003BDA
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54F | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
SNJ54F27J
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54F | Tube | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74AUP1T87DCKR
IC GATE XNOR 1CH 2-INP SC70-5
|
74AUP | Tape & Reel (TR) | Active | XNOR (Exclusive NOR) | 2 | Schmitt Trigger | 2.3V ~ 3.6V | 4mA, 4mA | 0.35V ~ 0.5V | 1.1V ~ 1.19V |
|
|
JM38510/33002B2A
MILITARY 6-CH, 4.5-V TO 5.5-V BI
|
54F | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
54F132DM
NAND GATE, F/FAST SERIES
|
54F | Bulk | Active | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 1mA, 20mA | 1.1V | 2V |
|
SN74F27NG4
IC GATE NOR 3CH 3-INP 14DIP
|
74F | Tube | Discontinued at | NOR Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74AUP1G14DBVT
IC INVERTER 1CH 1-INP SOT23-5
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 0.8V ~ 3.6V | 4mA, 4mA | 0.1V ~ 0.88V | 0.6V ~ 2.29V |
|
|
5962-9757701QDA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54F | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74AUP1G04DRYR
IC INVERTER 1CH 1-INP 6SON
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
SN74AUP1G04DCKRE4
IC INVERTER 1CH 1-INP SC70-5
|
74AUP | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
|
SNJ54F27FK
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54F | Tube | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
JM38510/33002BDA
MILITARY 6-CH, 4.5-V TO 5.5-V BI
|
54F | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
