| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LVC00AQPWRQ1
IC GATE NAND 4CH 2-INP 14TSSOP
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
SN7414N
IC INVERT SCHMITT 6CH 1-IN 14DIP
|
7400 | Bulk | Active | Inverter | 1 | Schmitt Trigger | 4.75V ~ 5.25V | 800µA, 16mA | 0.6V | 2V |
|
SN74ALVC32DR
IC GATE OR 4CH 2-INP 14SOIC
|
74ALVC | Tape & Reel (TR) | Active | OR Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN7400DRE4
IC GATE NAND 4CH 2-INP 14SOIC
|
7400 | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
SN74AUC1G86DCKR
IC GATE XOR 1CH 2-INP SC70-5
|
74AUC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 0.8V ~ 2.7V | 9mA, 9mA | 0V ~ 0.7V | 1.7V |
|
SN7404NG4
IC INVERTER 6CH 1-INP 14DIP
|
7400 | Tube | Discontinued at | Inverter | 1 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
SN74ALVC08PWRG4
IC GATE AND 4CH 2-INP 14TSSOP
|
74ALVC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74ALVC00D
IC GATE NAND 4CH 2-INP 14SOIC
|
74ALVC | Tube | Active | NAND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AUC1G02YZPR
IC GATE NOR 1CH 2-INP 5DSBGA
|
74AUC | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 0.8V ~ 2.7V | 9mA, 9mA | - | - |
|
SN7432N
IC GATE OR 4CH 2-INP 14DIP
|
7400 | Tube | Active | OR Gate | 2 | - | 4.75V ~ 5.25V | 800µA, 16mA | 0.8V | 2V |
|
CD54AC32F3A
MILITARY 4-CH, 2-INPUT, 1.5-V TO
|
54AC | Tube | Active | OR Gate | 2 | - | 1.5V ~ 5.5V | 24mA, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
SN74ALVC00NSR
IC GATE NAND 4CH 2-INP 14SOP
|
74ALVC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
