| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LVC04APWRE4
IC INVERTER 6CH 1-INP 14TSSOP
|
74LVC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AUP1G14DSFR
IC INVERT SCHMITT 1CH 1-INP 6SON
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 0.8V ~ 3.6V | 4mA, 4mA | 0.1V ~ 0.88V | 0.6V ~ 2.29V |
|
SN74AUP2G08RSER
IC GATE AND 2CH 2-INP 8UQFN
|
74AUP | Tape & Reel (TR) | Active | AND Gate | 2 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
SN74LVC1G00DBVRG4
IC GATE NAND 1CH 2-INP SOT23-5
|
74LVC | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74LVC2G32YEPR
IC GATE OR 2CH 2-INP 8DSBGA
|
74LVC | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
5962-8684401DA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54ALS | Tube | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74LVC2G14DBVRE4
IC INVERTER 2CH 2-INP SOT23-6
|
74LVC | Tape & Reel (TR) | Discontinued at | Inverter | 2 | Schmitt Trigger | 1.65V ~ 5.5V | 32mA, 32mA | 0.3V ~ 1.4V | 1.4V ~ 3.7V |
|
SN74LVC86AQPWREP
IC GATE XOR 4CH 2-INP 14TSSOP
|
74LVC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
SN74LVC2G00DCUTG4
IC GATE NAND 2CH 2-INP 8VSSOP
|
74LVC | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.58V ~ 1.65V | 1.07V ~ 3.85V |
|
|
SNJ54ALS09FK
IC GATE AND 4CH 2-INP 20LCCC
|
54ALS | Tube | Active | AND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 100µA, 4mA | 0.7V | 2V |
|
SN74LVC3G14DCURE4
IC INVERT SCHMITT 3CH 3IN 8VSSOP
|
74LVC | Tape & Reel (TR) | Discontinued at | Inverter | 3 | Schmitt Trigger | 1.65V ~ 5.5V | 32mA, 32mA | 0.3V ~ 1.4V | 1.4V ~ 3.7V |
|
SN74AUP3G14YFPR
IC INVERT SCHMITT 3CH 3IN 8DSBGA
|
74AUP | Tape & Reel (TR) | Active | Inverter | 3 | Schmitt Trigger | 0.8V ~ 3.6V | 4mA, 4mA | 0.1V ~ 0.88V | 0.6V ~ 2.29V |
