| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
74LS133SC
NAND GATE, TTL, PDSO16
|
74LS | Bulk | Active | NAND Gate | 13 | - | 4.75V ~ 5.25V | - | - | - |
|
SN74AHC1G09QDBVRQ1
AUTOMOTIVE, 1-CH,2-INPUT 2-V TO
|
Automotive, AEC-Q100, 74AHC | Tape & Reel (TR) | Active | AND Gate | 2 | Open Drain | 2V ~ 5.5V | -, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AC08PWR
IC GATE AND 4CH 2-INP 14TSSOP
|
74AC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74LVC2G04DBVRG4
IC INVERTER 2CH 2-INP SOT23-6
|
74LVC | Tape & Reel (TR) | Discontinued at | Inverter | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | - | - |
|
|
SN74HC21QPWRQ1
IC GATE AND 2CH 4-INP 14TSSOP
|
Automotive, AEC-Q100, 74HC | Tape & Reel (TR) | Active | AND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LS86AD
IC GATE XOR 4CH 2-INP 14SOIC
|
74LS | Tube | Discontinued at | XOR (Exclusive OR) | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
|
SN74HC14QPWRQ1HY
PROTOTYPE
|
Automotive, AEC-Q100, 74HC | Bulk | Active | Inverter | 6 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 1V ~ 3.2V | 1.5V ~ 4.2V |
|
SN74AC04NG4
IC INVERTER 6CH 1-INP 14DIP
|
74AC | Tube | Discontinued at | Inverter | 1 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74LVC1G00YEAR
IC GATE NAND 1CH 2-INP 5DSBGA
|
74LVC | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
SN74HC86QPWRG4Q1
IC GATE XOR 4CH 2-INP 14TSSOP
|
Automotive, AEC-Q100, 74HC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74AC05WBQARQ1
AUTOMOTIVE 8-CH 1.5V TO 5.5V INV
|
74AC | Tape & Reel (TR) | Active | Inverter | 6 | Open Drain | 1.5V ~ 5.5V | -, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
|
SN74LVC1G06YEAR
IC BUF INVERT 5.5V 5DSBGA/5WCSP
|
74LVC | Tape & Reel (TR) | Obsolete | Inverter | 1 | Open Drain | 1.65V ~ 5.5V | -, 32mA | 0.58V ~ 1.65V | 1.07V ~ 3.85V |
