| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN54ALS27AJ
IC GATE NOR 3CH 3-INP 14CDIP
|
54ALS | Tube | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
|
5962-9218201MDA
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54ACT | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
|
JM38510/65201B2A
MILITARY 4-CH, 2-INPUT, 2-V TO 6
|
54HC | Tube | Active | OR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
SN74AHC1G02DCK3
PROTOTYPE
|
74AHC | Bulk | Active | NOR Gate | 2 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74ACT11D
IC GATE AND 3CH 3-INP 14SOIC
|
74ACT | Bulk | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
|
SNJ54ALS04BJ
IC INVERTER 6CH 6-INP 14CDIP
|
54ALS | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74LVC1G11YZPR
IC GATE AND 1CH 3-INP 6DSBGA
|
74LVC | Tape & Reel (TR) | Active | AND Gate | 3 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
SNJ54ACT11FK
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54ACT | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
|
JM38510/65202BCA
MILITARY 4-CH, 2-INPUT, 2-V TO 6
|
54HC | Tube | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
74AHC1GU04DBVTG4
IC INVERTER 1CH 1-INP SOT23-5
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.3V ~ 1.1V | 1.7V ~ 4.4V |
|
|
SNJ54LVC86AW
MILITARY 4-CH, 2-INPUT, 2-V TO 3
|
54LVC | Tube | Active | XOR (Exclusive OR) | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
SN74AHC1G09DCKR-P
PROTOTYPE
|
74AHC | Bulk | Active | AND Gate | 2 | Open Drain | 2V ~ 5.5V | -, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
