| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54ALS133W
IC GATE NAND 1CH 13-INP 16CFP
|
54ALS | Tube | Active | NAND Gate | 13 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74LVC1G386DRYR
IC GATE XOR 1CH 3-INP 6SON
|
74LVC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 3 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
CD4093BPWR
IC GATE NAND 4CH 2-INP 14TSSOP
|
4000B | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 3V ~ 18V | 3.4mA, 3.4mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
SN74AS10NSR
IC GATE NAND 3CH 3-INP 14SOP
|
74AS | Tape & Reel (TR) | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
|
SNJ54LVC32AFK
MILITARY 4-CH, 2-INPUT, 2-V TO 3
|
54LVC | Tube | Active | OR Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
CD74AC02M96
IC GATE NOR 4CH 2-INP 14SOIC
|
74AC | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 1.5V ~ 5.5V | 24mA, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
SN74AS27DRE4
IC GATE NOR 3CH 3-INP 14SOIC
|
74AS | Tape & Reel (TR) | Obsolete | NOR Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
|
CD4025BM96
IC GATE NOR 3CH 3-INP 14SOIC
|
4000B | Tape & Reel (TR) | Active | NOR Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74LVC1G02DSFR
IC GATE NOR 1CH 2-INP 6SON
|
74LVC | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AC10N
IC GATE NAND 3CH 3-INP 14DIP
|
74AC | Tube | Active | NAND Gate | 3 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
CD74AC04E
IC INVERTER 6CH 1-INP 14DIP
|
74AC | Tube | Active | Inverter | 1 | - | 1.5V ~ 5.5V | 24mA, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
SN74AS02D
IC GATE NOR 4CH 2-INP 14SOIC
|
74AS | Tube | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
